Custom Modular Food Kiosks & Container Cafe Solutions

Launching a high-traffic quick-service restaurant (QSR), specialty coffee bar, or highway drive-thru demands spaces that merge visual appeal with commercial kitchen functionality. As a leading portable food kiosk manufacturer Kolkata, PortaSpaze builds turnkey food service units, bespoke container cafe design India solutions, and durable mobile restaurant spaces tailored for high-volume retail environments.

Whether you are establishing a stylish readymade coffee kiosk container in Kolkata’s commercial parks, deploying a prefabricated outdoor food stall along the NH6 corridor, or setting up a pop-up restaurant container in Durgapur, Haldia, or Dankuni, our structures arrive fully wired, pre-plumbed, and engineered for rapid commercial deployment.

Engineered for Food Safety, Aesthetics, and Mobility

Technical Specifications (Food Kiosk Base Build)

Underframe Substructure

60 mm x 60 mm Square Hollow Sections (SHS) treated with anti-corrosive primer coating

Corner Posts & Top Frame

Corner posts: 72 mm x 72 mm square pipe (up to 20 ft units) / 90 mm x 90 mm (30 ft to 40 ft modules). Top frame: 50 mm x 50 mm SHS.

External Shell (Walls & Roof)

1.2 mm thick corrugated Mild Steel (M.S.) sheets, continuously welded to ensure a weather-tight, rodent-proof envelope

Insulation & Thermal Barrier

25 mm thick high-density Glasswool insulation providing interior thermal regulation against exterior cooking heat and weather

Internal Wall & Ceiling Cladding

4 mm washable, non-porous Aluminium Composite Panels (ACP) or optional food-grade SS 304 backsplashes

Subfloor & Decking System

18 mm heavy Cement Fiber Board underlayment overlaid with anti-skid chequered aluminium plate or heavy-duty commercial vinyl

Access Doors & Service Hatches

1 No. 6 ft x 3 ft secure M.S. entrance door plus hydraulic/strut-assisted upward-opening M.S. serving hatch with customer ordering ledge

Ventilation & Exhaust Cutouts

Reinforced ventilation louvers, high-speed ceiling cage fan, and dedicated ceiling/wall cutouts for commercial kitchen exhaust hoods

Plumbing & Drainage Lines

Concealed CPVC freshwater lines, multi-compartment sink plumbing, grease-trap connection readiness, and centralized wastewater outlet

Protective Surface Coating

Anti-corrosive Red Oxide primer undercoat followed by dual coats of premium Synthetic Enamel or custom brand aesthetic finishes

Modular Food Kiosk Footprints & Variants

Compact Coffee & Snack Booth

8 ft x 8 ft / 10 ft x 8 ft (Height: 8.5 ft): Built on 60x60 mm SHS frames. Optimized for grab-and-go espresso bars, juice counters, and ice cream stalls with a single serving counter and compact equipment footprint.

Full-Service QSR Container

15 ft x 10 ft / 20 ft x 10 ft (Height: 8.5 ft): Built on 60x60 mm SHS with 72x72 mm corner posts. Configured with dual serving windows, dedicated prep zones, deep-sink plumbing, and high-load power banks for commercial cooking appliances.

Pop-Up Restaurant & Cafe Suite

30 ft x 10 ft / 40 ft x 10 ft (Height: 8.5 ft): Heavy-duty 72x72 mm SHS framework with 90x90 mm corner pillars. Features integrated indoor POS counters, full kitchen line space, and options for rooftop deck seating or customer walk-in ordering.

Frequently Asked Questions

How does a container cafe compare to traditional brick-and-mortar restaurant construction?

A modular food kiosk or container cafe cuts construction time by up to 70% and drastically lowers initial civil development costs. Because the unit is fully relocatable, brand owners retain structural asset value and can easily shift locations if foot traffic patterns change.

Can the kiosk support heavy commercial kitchen equipment?

Yes. Every PortaSpaze kiosk features an 18 mm cement fiber board subfloor capable of supporting heavy commercial refrigeration, ovens, and espresso machines. Electrical panels are custom-designed with dedicated high-amp MCBs to safely support high-wattage kitchen equipment.

What customized design features can be integrated into a container cafe?

We provide full bespoke customization including hydraulic service awnings, outdoor customer counter ledges, custom exterior branding colors, menu board backlighting, glass observation fronts, and rooftop terrace structural provisions with external access staircases.

Launch Your Modular Food & Beverage Concept Today

Bring your food brand to market faster with custom-engineered, durable, and fully plumbed container cafe and food kiosk solutions across Eastern India.
